Broadband Power Amplifier outstanding performance up to 22 GHz!
- Power Amplifier (PA)
| Part Num. | Data Sheet | F_Low Hz | F_High Hz | Gain | NF dB | Gain Flatness | OP1dB dBm | OPI3 dBm | DC (V) | DC (mA) | Price | Order |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PA700M800M | 700M | 800M | 35 | 4 | N/A | 28 | 33 | 5 | 2000 | $606.00 | Order | |
| PA800M900M | 800M | 900M | 34 | 4 | N/A | 28 | 34 | 5 | 2000 | $606.00 | Order | |
| PA1805M1880M | 1805M | 1880M | 38.5 | 4 | N/A | 28 | 35 | 5 | 2000 | $606.00 | Order | |
| PA1900M2000M | 1900M | 2000M | 37.5 | 4 | N/A | 28 | 36 | 5 | 2000 | $606.00 | Order | |
| PA2000M2300M | 2000M | 2300M | 35 | 4 | N/A | 28 | 36 | 5 | 2000 | $606.00 | Order | |
| PA2300M2400M | 2300M | 2400M | 35.5 | 4 | N/A | 28 | 36 | 5 | 2000 | $606.00 | Order | |
| PA2490M2690M | 2490M | 2690M | 32 | 4 | N/A | 28 | 35 | 5 | 2000 | $606.00 | Order | |
| PA3400M3800M | 3400M | 3800M | 35 | 4 | N/A | 28 | 35 | 5 | 2000 | $606.00 | Order | |
| PA0P2G22G | 200M | 22000M | 12 | 3 | N/A | 28 | 40 | 10 | 350 | $846.00 | Order |
